Portable Reverse Vending machine Recycling old Cloth / Bedding for
Supermarket
Brief Introduction :
Most of the clothes are textiles, which cannot be digested in a
normal environment. The common way to dispose of old clothes is to
incinerate them. Everyone knows that the earth's resources have
been greatly depleted, and it is inevitable to effectively realize
resource reuse and recycling.
Apparel Reverse Machine RVM-1106 (RVM) clothes recycling cabinets
can not only realize the recycling of clothes, but also recycle old
clothes, beddings, shoes, bags. User start operation by access APP or scan the QR Code or by manual
button.
Meanwhile RVM-1106 Apparel Reverse Machine (RVM) offer variety reward options for example coupon/ vouche, digital deposit,
donation and redeem gift based on the weight of recycling. With the
printing module suitable to print the coupon, token and vouchers.
Remote control management software collect and transfer the opeate
reycling data, reward data, data analysis, transportation route
optimization & etc to could server. with over flow alarms, abnormal
alarms, remote settings etc
Quick Detail:
1. Demo Screen:10"
2. Material types: garments waste, shoes, bag, beddings
3. multiple reward systems in digital deposit, coupon, donation,
redeem gift
4. optional with vend module, suitable for drinks, bottle water,
snack, shopping bag, and other products etc
5. Storage capacity: 20kgs
6. Over flow alarms
7. Ultraviolet ray & Ozone Sterilization up to 99.99%
8. built in integrated scale module
9. CCTV security camera
10. 4 protections-OVP,SCP, RVP, RCD
11. IP54 waterproof
12. Support software integarted
Parameters:
| Model# | RVM-1106 | Description: | Apparel RVM |
| Size (mm) | 1850H* 900L*600D | Container | Cloth, bag, shoes, bedding |
| Compactor | No | Sorted | NO |
| G.W | 210KGS | Storage capacity: | 20kgs |
| Voltage/ Frequency | AC110V, 230v, 50/60HZ
0.5A /10A | Output: | Max: 350W
Idle status: 150w |
| recognition system | integrated scale module | Reward | Coupon
Donation
Digital deposit
Redeem gift |
| Operated | QR code, APP | Display LCD | 10” |
| CCTV camera | yes | Working Temp
Humidity
Noise | -10℃ to +45℃
<95%,
<60db |
| Suitable for | Semi-Outdoor | Network Solution | LAN,GPRS, 3G, 4G |
| Operate software | a.Standard in English b.Customized c.Manual operate | Remote control software | a. Standard
b. Customized
c. Standalone |
Special
features | 1. UV sterilization
2. RVM with 4 protections
3. Over flow alarms
4. Abnormal alarms | Software integrated | Support |
